- 品牌/型号：高新/150
- 加工定制：是
- 重量：1000（kg）kg
- 类型：双螺杆混炼机
- 型号：150
- 别名：造粒机
- 主电动机功率：18.5（KW）
- 工作容积：150（L）
- 适用范围：聚氯乙烯、聚丙乙烯、低密度聚乙烯、高密度聚乙烯、线性低密度聚乙烯等各种软质塑料膜、袋、丝、带、片、管的废料
- 品牌：高新
- 生产能力：60-80（Kg/h）Kg/h
- 螺杆转速：660（r/min）r/min
- 外形尺寸：1500*700*1400（m）mm
- 螺杆直径：90（mm）mm
- 螺杆长径比：20:1
150型号PE塑料薄膜混炼机
用途：
本机应用日本先进技术、利用多刀快速粉碎、连续搅拌、混炼摩擦发热、急速冷却收缩原理，将塑料薄膜、丝、带、片、软塑料管、发泡料、降解料等废料与角料造成颗粒投入再生产，是目前最新型的塑料回收再生的造粒理想设备。
1、对聚氯乙烯、聚丙乙烯、低密度聚乙烯、高密度聚乙烯、线性低密度聚乙烯等各种软质塑料膜、袋、丝、带、片、管的废料与下脚料的回收，投入在生产。
2、对降解塑料薄膜与角料粉碎、造粒的回收再生产。
3、对化纤材料（涤纶、晴纶、丙纶等）进行粉碎、造粒，投入再生产的废丝处理。
4、一机多用。可替代混合机或干燥机。
主要特点：
A：粉碎、混合、着色能一次进行
B：机器占地面积小
C：机械结构简单、操作方便
D：刀刃间隙可调，换刀方便
E：生产效率高、耗能低（日产量1吨，耗电量200度）
F：低温造粒，基本不破坏原料分子结构，不损坏物理性能
主要技术参数:
Model | 150mm | 300mm |
筒体容量 | 150L | 300L |
产量 | 60-80kg/h | 200-300kg/h |
主机功率 | 18.5kw | 37kw |
加水装置 | 125w | 125w |
加热功率 | 3.6kw | 3.6kw |
主轴转速 | 660r/min | 660r/min |
机器尺寸 | 1500×700×1400mm | 2000×1000×1400mm |
USE:
The machine adopts Japanese design principles, employs the principles of grinding rapidly, agitating continuously, milling and fractioning to be heated with multi-knives and cooling and contracting. It produces granules from waste materials and angle materials such as the plastic films, filament, ribbons, pieces, soft plastic pipes, foaming materials, and degrading materials, and puts then into reproduction .It is the latest ideal granulating equipment to recycle plastics and reproduce.
Main Functions:
1. Recycle the waste materials and leftover bits and pieces of various flexible plastic films, bags, filament, ribbons, pieces, and pipes such as polyvinyl chloride, polyethylene of higher density, and linear polyethylene of lower density, and put them into reproduction.
2. Recycle and reproduce the grinding and granulating of degrading plastic films and angle materials.
3. Grind chemical fiber waste materials, and process the waste filament that has been put into reproductions.
4. The machine is applied in many respects. It can be substitute for blending machine or dryer.
Main Features:
A: Milling, mixture and staining can be processed all in one
B: The machine takes up little area of land
C: It is characterized by simple structure and ease of operation
D: The interstitial of the blade can be adjusted with convenience of replacing.
E: It is characterized by high efficient in production and low consumption(1 ton of daily production ,and 200 degrees of electricity consumption ).
F: Granulate at lower temperature, do not damage molecular structure of materials basically, and do not damage physical performance.
Main Technical Variables:
Model | 150mm | 300mm |
Capacity of Barrel | 150L | 300L |
Output Capacity | 60-80kg/h | 200-300kg/h |
Main Motor Power | 18.5kw | 37kw |
Water Adding Device | 125w | 125w |
Heating Power | 3.6kw | 1.5kw |
Rotary Speed of Main Shaft | 660r/min | 660r/min |
Overall Dimensions | 1500×700×1400mm | 2000×1000×1400mm |
