| 型号 | GZ-700/900 |
|---|---|
| 品牌 | Beiguo |
1、用途Applications
主要制作无纺布的平口手挽袋、礼品袋、无纺布服装包装袋等。
The main production of non-woven bags for flat Bags, gift bags, Non-woven clothing bags, etc.
2、技术参数Main Technical Parameters
电源 | Voltage | 三相四线制 50Hz 380V/220V |
功率消耗 | Power | 7.5kw |
放卷**大直径 | Diameter of unwinder | 600mm |
放卷宽度 | Width of unwinder | 650mm, 850mm |
制袋长度 | Length of making bag | 40-650mm |
制袋宽度 | Width of making bag | 40-850mm |
3、性能特点Features
伺服电机控制，步进电机控制（任选） | Servo motor control, stepper motor control (optional) |
PLC人机界面操作，7”彩色触摸屏 | PLC,man-machine interface control, 7” touch screen |
变频电机调速 | Frequency Motor Speed Control |
光电跟踪 | Electro-optical tracking |
自动纠偏放料 | Automatic correction discharge |
自动上拉链超声波热合 | Automatic zipper ultrasonic heat sealing |
超声波边封、底封 | Ultrasonic side seal, bottom seal |
边料裁切收废边机收卷 | Edge material cut to close the waste side of machine winding |
