用 途：
用于吹制低密度聚乙烯（LDPE）、高密度聚乙烯（HDPE）塑料薄膜。 可制成各种背心袋、平品袋、广泛应用于食品、服装、纺织、工业等包装。
Performance：
It is used for blowing various plastic film of low density polyethylene (LDPE),high density polyethylene (HDPE)。And it is a king of ideal equipment for making s vest bags, flat bag etc. Can Which are widely used for packing food,garments and textile，industrial products etc…
主要技术参数:
型号 | Model | SD-45 | SD-50 |
螺杆直径(mm) | Diameter Of Screw(mm) | φ45 | φ50 |
薄膜折径(mm) | Max.Folding Width Of Film (mm) | 100-450 | 100-550 |
薄膜单面厚度(mm) | Thickness Of Blowing Film (mm) | 0.01-0.10 | 0.01-0.10 |
*大挤出量(kg/h) | Max.Extrusion Output (kg/h) | 25-30 | 30-35 |
长径比 | L/D | 28:1 | 28:1 |
主机功率(KW) | Driving Motor (KW) | 7.5 | 11 |
牵引电机功率(KW) | Take-up Motor (KW) | 0.75 | 1.1 |
加热功率(KW) | Heating Power (KW) | 11 | 13 |
外形尺寸(mm) | Outline Diameter(mm) | 2200×1400×2200 | 2300×1400×2200 |
机重(T) | Weight(T) | 1.3T | 1.4T |
