主要应用(Applications): 主要应用于：适用于工业、科研、机械领域等各种小空间的测量和控制。Mainly used for force measurement in different smallspace,industrial,scientific and machine research.
特点（Features）: 合金钢制传感器Alloy steel sensor磨合式结构，压式承载，安装使用非常方便灵活Break-in type structure，Compressiontype load cell, Installation using very convenient.安全防爆型产品，可用于恶劣环境及危险性场合Safe and anti-explosive product, can be used in atrocious environment and hazardous areas.体积小巧，外型美观。Volume is small and exquisite appearance| 灵敏度 Sensitivity | m V/V | 1.0±10% | | 综合误差Total error | %F.S | 0.1 | | 蠕变（30分钟）Creep(30min) | %F.S | 0.05 | | 零点平衡Zero balance | %F.S | ±0.1 | | 零点温度影响 TCO | %F.S/10℃ | 0.05~1 | | 输出温度影响 TC SPAN | %F.S/10℃ | 0.05~1 | | 输入阻抗 Input resistance | Ω | 385±10 | | 输出阻抗 Output resistance | Ω | 350±5 | | 绝缘电阻 Insulation resistance | MΩ | ≥5000 | | 工作温度范围 Operating Temp R | ℃ | -10~50 | | 安全过载 Safe load limit | %F.S | 150 | | 极限过载 Lateral load limit | %F.S | 200 | | 推荐激励电压Recommend excititati | VDC | 10 | | **大激励电压 Maximun excitati | VDC | 15 | | 密封等级Protection Class | IP67 | 67 | | 材质Construction | 不锈钢Stainless steel | | | 电缆Cable | Length: 3mDiameter:￠2.5~3mm |
|
|
